Advance Paris X-i1100 Integrated Amplifier

The Advance Paris X-i1100 has lots of power and input options. This unit can drive almost any pair of speaker with ease.

The DAC has two digital signal receivers: an X-Mos processor and a USB3318 with jitter correction for the USB input and a Cirrus Logic CS8416 for all the others, AES and S / PDIF. The chosen converter, a Burr Brown PCM1796, handles signals up to 192 kHz at 24 bits. Metal layer resistors and polypropylene capacitors contribute to the quality of restitution of this integrated amplifier. Mounted on large heat sinks, the amplification boards, connected to the output terminals by means of cables of 4 mm2 cross-section, have a triple push-pull per channel, so three pairs of bipolar transistors NJW0281 G and NJW0302G.

 The X-i1100 can operate at up to 45W in Class A-like mode and switches to Class AB beyond when the "High Bias" switch on the back of the device is activated. The mechanical construction has also been meticulous: five compartments forming as many galvanic insulations and contributing to the rigidity of the X-i1100 are integrated into the chassis. Steel frame topped by black aluminum sidewalls and openwork cover ensures optimum ventilation of the X-i1100.

• Output Power 8-ohms: 2x220W RMS.
• Output Power 4-ohms: 2x400W RMS.
• Frequency Response: 10Hz – 70kHz. Tone: +/- 10db.
• Distortion: 0.025%.
• Signal to Noise Ratio: >102 db.
• Channel Separation: >75 db.
• In level (CD/AUX): 500mV.
• Phono MM/MC Entry Level: 7mV.
• Inputs: 1x Phono, 1x Amp Input, 1x CD, 1x Tuner, 2x Auxiliary, 1x XLR, 4x Optical,2x Coaxial, 1x USB-B, 1x AES/EBU.
• Outputs: 1x Record/Subwoofer Out, 1x Pre-Out RCA.

Dimensions: 17” D x 19” W x 9” H

Weight: 48 lbs.
