ifi

ifi ZEN DAC V2

Free Shipping
$299

Only 7 in stock!

This ZEN DAC V2 is the same award-winning hi-res USB DAC/headphone amp as before, but with added oomph!

iFi  upgraded its digital engine from an 8 core XMOS chip to a 16 core chip. It’s ultra-capable while still being super-affordable.

Compact enough to use as a USB DAC/amp on your work desk and stylish enough to use at home with your favourite active speakers or amp, it delivers a level of specification and performance that punches above its super-affordable price tag.

The ZEN DAC V2 supports PCM and DXD to 32-bit/384kHz, DSD256 and MQA. DSD remains ‘bit-perfect’ thanks to the True Native Burr-Brown chip design.

Add a high quality DAC your computer and get more from your headphones and stereo system.

This superb hi-res USB DAC/headphone amp delivers a level of specification and performance that punches above its super-affordable price tag.

The ZEN DAC supports PCM and DXD to 32-bit/384kHz, DSD256 and MQA. DSD remains ‘bit-perfect’ thanks to the True Native Burr Brown chip design.

  • Input USB3.0 B Socket (USB2.0 compatible)
  • Formats DSD256/128/64, Octa/Quad/Double/Single-Speed DSD DXD(384/352.8kHz), PCM(384/352.8/192/176.4/96/88.2/48/44.1kHz) MQA
  • DAC Bit-Perfect DSD & DXD DAC by Burr Brown
  • Line Section Output Audio RCA (SE) — 2.1V fixed 1V / 3.3V max. (variable)
  • 4.4mm Pentaconn (BAL) — 4.2V fixed 2V / 6.2V max. (variable)
  • Zout <= 200 Ohm (BAL) <= 100 Ohm (SE)
  • SNR < -116dB(A) @ 0dBFS (BAL/SE)
  • DNR > 116dB(A) @ -60dBFS (BAL/SE)
  • THD+N < 0.0015% @ 0dBFS (BAL/SE)

Headphone Section

  • Output Power (@1% THD) 4.4mm Pentaconn (BAL)
  • 330mW@32 Ohm; 6.6V@600 Ohm;
  • 16 Ohm - 600 Ohm Headphone
  • 6.3mm S-BAL (SE)
  • 230mW@32 Ohm; 3.3V@600 Ohm
  • 16 Ohm - 600 Ohm Headphone
  • Note: Using 5v power. If powered from USB, power output may vary.
  • Output Impedance < 1 Ω (BAL/SE)
  • THD & N < 0.005% (125mW @ 32R)
  • SNR > 113dBA (6.2V BAL/3.3V SE)
  • Power consumption < 1.5W via USB power OR 5v DC (power supply not included)

Dimensions. 4.6" W x 3.93" D x 1.18"

Weight 0.8 kg (1.8 lbs)

Warranty: 1 year replacement
